Description
Characteristics
– Operating temperature: – 30°C to +70°C
– Storage temperature: – 55°C to + 85°C
– Shocks on the base: 9g for the 3 axis
– Vibrations: Less than 10Hz: 2mm half peak amplitude 10Hz to 100Hz: 100mm/s, above 100Hz: 8g
– Shunt power supply: max 150V – 50/60 Hz- Rated overload current: 10A – 10s
– Electronic protection: (in the event of overload, short-circuit, loss of voltage sensing) this acts to restore the value of the excitation current to 1A after 10 s. The alternator must be stopped (or the power switched off) in order to reset the protection.
– Fuse: F1 on X1, X2. 10A ; slow – 250V – Voltage sensing : 5 VA isolated via transformer
