Description
Why Choose Donaldson DuraLite™ Air Cleaners?
Rugged, lightweight, self-supporting, and completely disposable combination air cleaner and filter.
• Function well under severe pulsation conditions, particularly two- and three-cylinder engines.
• Vibration-resistant media is secured into molded housings of rugged ABS plastic—so they don’t fall apart as other designs might.
• Easy to install, durable, and reliable.
• Completely disposable — acceptable for normal trash pick-up (DuraLite should not be incinerated).
Attributes
Outlet Diameter 76.2 mm (3.00 inch)
Body Diameter Maximum 215.9 mm (8.50 inch)
Body Length 127 mm (5.00 inch)
Efficiency Test Std ISO 5011
Rated Flow LR 4.3 m³/min (152 cfm)
Rated Flow MR 5.1 m³/min (180 cfm)
Rated Flow HR 6.1 m³/min (215 cfm)
Restriction LR 102 mm H2O (4.02 inch H2O)
Restriction MR 152 mm H2O (5.98 inch H2O)
Restriction HR 203 mm H2O (7.99 inch H2O)
Family ECC
Type Primary
Style Round
Brand DuraLite™
Media Type Cellulose
