Description
Technical Specifications
Port Connection: NG06, CETOP 03
Poppet Style: A, B
Cracking Pressure: 1 bar
Maximum Operating Pressure (bar): 350
Mounting Type: Sandwich plate
Operation Type: Pilot
Actuation Type: Hydraulically
Product Series: Check valve
Weight: 1.8 kg
Body Material: Steel
Configuration: N/A
Connection Size: N/A
Connection Type: N/A
Cracking Pressure: 1.0 bar
Flow Direction: N/A
Maximum Flow Rate: 60 L/min
Maximum Operating Temperature: 60 °C
Minimum Operating Temperature: -20 °C
Seal Material: FPM
Opening Pressure Ratio: 1:3
