Description
Technical Specifications
Cracking Pressure (psi): 5
Rated Flow (gpm): 60
Seal Material: Nitrile
Flow Rate: 60 Gal/min, 225 L/min
Maximum Inlet Pressure Rating: 5000 psi, 350 bar
Leak Rate: 5 @ 5000 PSI (350 BAR) drops/min
Cavity Size: C16-2
Cracking Pressure: 5 psi, 0.3 bar
Seal Material: Nitrile
Operating Temperature: -30° to +250° °F, -34° to +121° °C
Valve Material: All parts steel. All operating parts hardened steel
Maximum Kinematic Viscosity: Mineral-based or synthetic with lubricating properties at viscosities of 45-2000 SSU (6 to 420 cSt) cSt
Filter Efficiency Rating: ISO 4406 18/16/13, SAE Class 4
Weight: 0.6 lb, 0.27 kg
Installation Torque: 73 lb-ft, 99 Nm
Function: Standard
