Description
Specification
Hydraulic Fluid – Mineral Oil
Fluid Temp Range – -10 to +80°C
Stroking Speed – Up to 0,5 m/s
Max presure in Bars 210
Shaft Diameter in Inch 1.1/2
Piston Diameter in Inch : 3
Sroke in inch : 14
Closed Center in mm : 616
Pin Dimansions in mm : 25
Port size : 1/2 NPT
