Description
Technical Specifications
Configuration: Normally Closed
Actuation Type: Electrical
Seal Material: D-Ring (Standard)
Wire Mesh Screen Included: No
Flow Rate: 15 Gal/min, 60 L/min
Maximum Inlet Pressure Rating: 5000 psi, 350 bar
Configuration: Normally Closed
Actuation Type: Electrical
Seal Material: D-Ring (Standard)
Wire Mesh Screen Included: No
Maximum Flow Rate: 15 Gal/min, 60 L/min
Mounting Type: Screw in cartridge valve
Flow Direction: Side to Nose (2-1)
Operation Type: Solenoid operated
Maximum Operating Pressure: 5000 psi, 350 bar
Leak Rate: 5 drops/min
Cavity Size: C10-2
Function: 2-way
Free Reverse Flow: Yes
Override Functionality: N/A
Adjustment Mechanism: N/A
For Fluid Type: Mineral-based or synthetic hydraulic fluids
Maximum Kinematic Viscosity: 45-2000 SSU (6 to 420 cSt)
Filter Efficiency Rating: ISO 4406 18/16/13, SAE Class 4
Valve Material: All parts steel. All operating parts hardened steel
Installation Torque: 51-55 lb-ft, 69-75 Nm
Coil Nut Tightening Torque: 5-7 lb-ft, 7-10 Nm
Operating Temperature: -35 to +200 °F, -37 to +93 °C
Maximum Operating Temperature: +200 °F, +93 °C
Minimum Operating Temperature: -35 °F, -37 °C
Coil Type: 5/8″ Super Coil
Input Voltage: 85% of rated voltage at 72°F (20°C) min
Response Time: 80 ms
Weight: 0.41 lb, 0.2 kg
