Description
Specifications
Attributes
Inlet Diameter 152.5 mm (6.00 inch)
Outlet Diameter 127 mm (5.00 inch)
Body Diameter Maximum 330 mm (12.99 inch)
Body Length 446.5 mm (17.58 inch)
Overall Length 588 mm (23.15 inch)
Rated Flow LR 13 m³/min (459 cfm)
Rated Flow MR 19 m³/min (671 cfm)
Rated Flow HR 24 m³/min (848 cfm)
Restriction LR 100 mm H2O (3.94 inch H2O)
Restriction MR 200 mm H2O (7.87 inch H2O)
Restriction HR 300 mm H2O (11.81 inch H2O)
Style Radialseal
Family FRG
Brand RadialSeal™
