Description
Attributes
Outer Diameter 107.7 mm (4.24 inch)
Thread Size 1-14 UN
Length 143.5 mm (5.65 inch)
Gasket OD 90 mm (3.54 inch)
Gasket ID 80 mm (3.15 inch)
Bowl Thread 3 3/4-10 BUTT (ANSI B1.9)
Efficiency 90% 30 micron
Efficiency Test Std ISO 4402/11171
Flow Direction Outside-In
Type Water Separator
Style Spin-On
Primary Application RACOR R90P
