Description
Technical Specifications
Rated Flow (gpm): 15
Adjustment Type: Screw Adjust
Pressure Range Adjustment (psi): 600-3000
Cracking Pressure (psi): N/A
Seal Material: D-Ring (Standard)
Flow Rate: 15 Gal/min, 56.3 L/min
Maximum Inlet Pressure Rating: 5500 psi, 380 bar
Maximum Tank Pressure: 5000 psi, 350 bar
Maximum Drain Flow Rate: 0.25 Gal/min, 0.94 L/min
Cavity Size: C10-3
Pressure Control Range: 600-3000 psi, 41.4-207 bar
Adjustment Mechanism: Screw Adjust
Standard Setting Pressure: 1500 psi, 103.5 bar
Pressure Control Sensitivity: 855 per turn psi, 58.9 per turn bar
Cracking Pressure: N/A
Seal Material: D-Ring (Standard)
Operating Temperature: -50° to +270° °F, -45° to +132° °C
Valve Material: All parts steel. All operating parts hardened steel
Body Material: –
Maximum Kinematic Viscosity: Mineral-based or synthetic with lubricating properties at viscosities of 45-2000 SSU (6 to 420 cSt) cSt
Filter Efficiency Rating: ISO 4406 18/16/13, SAE Class 4
Weight: 0.5 lb, 0.23 kg
Installation Torque: 51-55 lb-ft, 69-75 Nm
Function: Reducing
