Description
Technical Specifications
Adjustment Type: Screw Adjust
Pressure Range Adjustment (psi): 500-5000
Rated Flow (gpm): 80
Seal Material: Nitrile
Flow Rate: 80 Gal/min, 302.8 L/min
Maximum Inlet Pressure Rating: 5500 psi, 380 bar
Maximum Tank Pressure: 5000 psi, 350 bar
Maximum Pressure Setting: 5000 psi, 350 bar
Leak Rate: 5 @ 100 psi (6.8 bar) cm3/min
Cavity Size: C16-2
Pressure Control Range: 500-5000 psi, 34.5-345 bar
Adjustment Mechanism: Screw Adjust
Standard Setting Pressure: 2500 psi, 172.4 bar
Pressure Control Sensitivity: 1711 per turn psi, 118 per turn bar
Reseat Pressure: 80%
Seal Material: Nitrile
Operating Temperature: -30° to +250° °F, -34° to +121° °C
Valve Material: All parts steel. All operating parts hardened steel
Maximum Kinematic Viscosity: Mineral-based or synthetic with lubricating properties at viscosities of 45-2000 SSU (6 to 420 cSt) cSt
Filter Efficiency Rating: ISO 4406 18/16/13, SAE Class 4
Weight: 2 lb, 0.9 kg
Installation Torque: 56 lb-ft, 76 Nm
