Description
Technical Specifications
Rated Flow (gpm): 20
Adjustment Type: Screw Adjust
Cracking Pressure (psi): N/A
Pressure Range Adjustment (psi): 500-5000
Seal Material: D-Ring (Standard)
Flow Rate: 20 Gal/min, 75 L/min
Maximum Inlet Pressure Rating: 5500 psi, 380 bar
Maximum Tank Pressure: 5000 psi, 350 bar
Maximum Pressure Setting: 5000 psi, 350 bar
Leak Rate: 5 @ 75% Crack Pressure drops/min, .33 @ 75% Crack Pressure cm3/min
Cavity Size: C10-2
Pressure Control Range: 500-5000 psi, 34.5-345 bar
Adjustment Mechanism: Screw Adjust
Standard Setting Pressure: 2500 psi, 172.4 bar
Pressure Control Sensitivity: 589 per turn psi, 40.6 per turn bar
Reseat Pressure: 85 %
Cracking Pressure: N/A
Seal Material: D-Ring (Standard)
Operating Temperature: -50° to +270° °F, -45° to +132° °C
Valve Material: All parts steel. All operating parts hardened steel
Body Material: N/A
Maximum Kinematic Viscosity: Mineral-based or synthetic with lubricating properties at viscosities of 45-2000 SSU (6 to 420 cSt) cSt
Filter Efficiency Rating: ISO 4406 18/16/13, SAE Class 4
Weight: 0.5 lb, 0.23 kg
