Description
Features Specifications
Digital switch input 5
Analogue resistive inputs 3
Analogue current/voltage input 1
Mains voltage input (AMF) Yes
DG alternator voltage input,
D+ charging alternator I/O Yes
DG alternator current input Yes
Engine speed input via MPU Yes
Digital outputs 6
Real Time Clock for event logs and Auto exercise mode Yes
USB I/O port for laptop access Yes
EEPROM for extended event logs OR regional languages Yes
CANbus Engine Interface Yes
RS-485 Interface for Modbus Yes
DC battery supply voltage (with -32 V reverse protection) 8 to 28 V
Operating temperature range -20 to 65 °C
Protection class with gasket (included) IP65
Warning auto clear enable/disable Yes
Fuel reference selection input Yes
On the fly mode change when engine is healthy/engine off Yes
