Description
Technical Specifications
Pressure Range Adjustment (psi): 145-6000
Adjustment Type: Screw Adjust
Rated Flow (gpm): 106
Seal Material: Nitrile
Flow Rate: 106 Gal/min, 400 L/min
Maximum Inlet Pressure Rating: 6000 psi, 420 bar
Maximum Tank Pressure: 6000 psi, 420 bar
Maximum Pressure Setting: 6000 psi, 420 bar
Leak Rate: 100 @ 1451 psi (100 bar) cm3/min
Cavity Size: C16-2
Pressure Control Range: 145-6000 psi, 10-420 bar
Adjustment Mechanism: Screw Adjust
Standard Setting Pressure: 2900 psi, 200 bar
Pressure Control Sensitivity: 800 per turn psi, 55 per turn bar
Reseat Pressure: N/A
Seal Material: Nitrile
Operating Temperature: -30° to +250° °F, -34° to +121° °C
Valve Material: All parts steel. All operating parts hardened steel
Maximum Kinematic Viscosity: Mineral-based or synthetic with lubricating properties at viscosities of 45-2000 SSU (6 to 420 cSt) cSt
Filter Efficiency Rating: ISO 4406 18/16/13, SAE Class 4
Weight: 1.26 lb, 0.57 kg
Installation Torque: 74 lb-ft, 100 Nm
